Long flexible printed circuit enables solar-powered drone flight

0

Printed circuit supplier Trackwise has produced  a 26m (85ft)  long multilayer, flexible printed it claims is the  world’s longest ever produced, for distributing power and control signals across the wings of a solar-powered drone.

The flexible printed circuit (FPC) is one of more than 50 supplied by the UK-based company for the drone.

The entire interconnect system of the vehicle is made of FPCs, representing an estimated total systems weight saving of 60% compared  to the use of traditional wire harness, says Trackwise.

The weight-saving will enable the drone, which is being manufactured in the USA, to achieve higher payload and/or improved speed and range.

Trackwise’s FPCs are made using a patented, reel-to-reel manufacturing technique that enables the company to produce FPCs of potentially unlimited length.

The FPC is based on a polyimide substrate. Testing has shown that the planar structure of the circuit dissipates heat better than conventional wiring, enabling higher current carrying capacity for a given weight of copper conductor.

CEO of Trackwise, Philip Johnston, said, “There are many new applications emerging for long, lightweight FPCs but aerospace is a natural fit: weight savings, high reliability and cost effectiveness are critical.”
